Terraform Multi-Cloud Provisioning: How the Runner Builds Kubernetes on AWS, GCP, and Azure

Terraform multi-cloud sounds clean on a slide. In production it is provider APIs, state races, and 10-15 minute cluster creates that still have to feel reliable to the user.

The Runner is the workhorse of PipeOps. When someone clicks “Create Server,” the Runner is what actually makes multi-cloud Kubernetes real: Terraform across AWS, GCP, Azure (and lighter paths for DO/Linode), managed state, failures, and live logs.

It’s a Go service that provisions infrastructure across multiple cloud providers, manages state, handles failures, and streams logs back in real-time. The same Runner also handles application deployments once infrastructure is provisioned.

The Flow

  1. Controller receives “provision cluster” request
  2. Validates params (region, instance types, node count)
  3. Queues job in RabbitMQ
  4. Runner picks up job from queue
  5. Loads our custom infrastructure modules
  6. Injects customer-specific variables
  7. Executes provisioning workflow
  8. Streams output back to user in real-time
  9. Extracts outputs (cluster endpoints, credentials)
  10. Updates database with results
  11. Triggers k8-agent deployment
  12. Marks job complete

Average time: 10-15 minutes for a new cluster. Faster for updates.

Multi-Cloud Complexity

Supporting AWS, GCP, Azure, DigitalOcean, and Linode meant handling each provider’s quirks:

AWS: VPCs, subnets, security groups, IAM roles. Everything needs tagging. EKS takes 12 minutes to provision.

GCP: Networks, subnetworks, firewall rules, service accounts. GKE is faster (8 minutes) but weird networking defaults.

Azure: Resource groups, virtual networks, NSGs, managed identities. AKS takes forever (15 minutes). Their API is slow.

DigitalOcean: Simple but limited. K8s setup is quick (6 minutes) but features are basic.

Linode: Similar to DO. Fast but fewer regions.

The Runner abstracts all this. User picks “AWS, us-east-1, 3 nodes” and we handle the rest.

State Management

With hundreds of customers and thousands of clusters, infrastructure state management is critical.

For BYOC (Bring Your Own Cloud) deployments, each cluster’s state is stored in your cloud provider account. You bring your AWS/GCP/Azure account, we provision infrastructure in it, and state lives in your bucket.

Each BYOC cluster gets:

  • Separate state file in your S3/GCS bucket
  • State locking mechanisms (DynamoDB for AWS, native for GCS)
  • Automated backups every hour
  • Versioning enabled (can rollback if needed)

State bucket structure in your account:

s3://customer-state-bucket/
  cluster-production/
    state.tf
    backups/
      state.2024-10-31.tf
  cluster-staging/
    state.tf
    backups/
      state.2024-10-31.tf

For PipeOps-managed infrastructure (Nova multi-tenant clusters), we handle state internally with the same backup and versioning guarantees.

If state gets corrupted (it happens), we restore from backup automatically.

Infrastructure Modules

We don’t provision infrastructure from scratch for each cluster. The Runner uses a modular approach with well-tested components:

Kubernetes Module: Core cluster provisioning (EKS, GKE, AKS) Network Module: VPC, subnets, routing, security groups Essentials Module: Ingress controllers, cert-manager, monitoring stack Orchestration Layer: Combines modules into complete infrastructure stacks

These modules are versioned and locked to prevent breaking changes. Updates are tested in staging environments before gradual rollout to production clusters.

Error Handling

Infrastructure provisioning fails. A lot. Our error handling:

Cloud API failures: Retry with exponential backoff (up to 5 times)
Quota limits: Surface clear error with fix
Invalid config: Validate before execution
Partial failures: Mark what succeeded, offer cleanup or continue
Process crashes: Capture logs, save state, alert ops team

When provisioning fails, users get:

  1. What went wrong
  2. At what step
  3. How to fix it
  4. Option to retry or rollback

No “Something went wrong.” Actual information.

Concurrent Execution

The Runner handles hundreds of concurrent jobs:

  • Each job gets isolated workspace
  • Separate working directories
  • No shared state between jobs
  • Resource limits per job (CPU, memory)
  • Job timeouts (30 minutes max)

We can run 50+ Terraform jobs simultaneously. The bottleneck is cloud provider APIs, not our infrastructure.

Streaming Logs

Users watch provisioning output in real-time in the dashboard. It’s WebSocket-based:

Runner → RabbitMQ → Controller → WebSocket → Browser

The provisioning process outputs to stdout/stderr, we capture it, send to queue, controller forwards to connected clients. They see everything as it happens.

Cleanup on Failure

If provisioning fails halfway, we clean up what was created. Otherwise users end up with orphaned resources costing money.

The cleanup process:

  1. Mark resources that were successfully created
  2. Run cleanup procedures on partial state
  3. If cleanup fails, retry up to 3 times
  4. If still failing, alert ops team
  5. Manually investigate and resolve

We log everything for post-mortem analysis.

Variable Injection

Customers don’t write infrastructure code. They fill out a form, we generate the required configuration:

cluster_name: "customer-production"
region: "us-east-1"
node_count: 3
instance_type: "t3.medium"
enable_monitoring: true
backup_schedule: "daily"

We validate types, ranges, and dependencies before execution. Invalid config never reaches the provisioning stage.

Cost Estimation

Before provisioning, we estimate monthly costs using cloud provider pricing APIs and our infrastructure module calculations.

“This cluster will cost approximately $450/month.”

Not perfect (data transfer and storage costs are hard to predict), but close enough for budget planning.

What’s Next

Working on:

  • Drift detection (alert when manual changes diverge from Terraform)
  • Cost optimization recommendations
  • Faster provisioning (parallel resource creation where safe)
  • Better rollback mechanisms
  • Support for more cloud providers

The Runner evolved from “provision clusters” to handling all infrastructure operations. Updates, scaling, configuration changes, teardowns - all go through the Runner now.

These infrastructure patterns represent two years of production learnings, edge cases, and optimizations across multiple cloud providers.

FAQ: Terraform multi-cloud

How do you do Terraform multi-cloud for Kubernetes?

One Runner service executes provider-specific Terraform modules (EKS, GKE, AKS, etc.) with a shared job queue, remote state, and the same API surface for “create / update / destroy cluster.” Customers do not write the Terraform; the platform injects validated variables.

Why not one giant multi-cloud module?

Provider quirks win. AWS, GCP, and Azure disagree on networking, IAM, and timing. Separate modules behind one orchestrator keep failures local and logs readable.
